Χαρακτηριστικά:
100-240VAC input
SMPS Adaptor.
Working temperature with 60 oC ,
100% full load burn-in test,
2 years warranty
OUTPUT: DC Voltage 12V Voltage Range:11.8V-12.3V Rated Current:0-4A Rated Power:48W Ripple & Noise:200mVp-p INPUT:Voltage Range:100-240VAC Frequency Range:50 - 60Hz Full Load Efficiency(Typ.):85% Input Current Limiting: The input current should < 0.6A, under Min. AC input and full loads. Inrush current:<50A Protection:Short Circuit:An output short circuit will automatically enter the protected status .The
power supply will protectwithout damage to overseers of to the unit (components,
connectors, etc) under the protection of process. Over Voltage: Min 11.5V, Max 12.5V.Over Current:The power supply shall meet the limitation requirement Min 3.8A,
Max 4.5A without any damage, theunit shall recover the function
after the protection is removed.
Over Temperature; 100°C±10 °Cshut down o/p voltage, re-power on to recover:Hold up Time：>10mS at 100Vac, the output loading should be set up with fullload during the test. Start up Time :<3S at 100Vac, the output loading should be set up withfull load during the test.
| Κατηγορία | HRU ADAPTER |
|---|
